  • 3.5SD
  • 3.5SD

    Applications

    For water supply from wells or reservoirs

    For domestic use, for civil and industrial application:

    Forgarden use and irrigation


    Operating conditions

    Maximum fluid temperature up to +35C

    Maximum sand content:0.25%

    Minimum well diameter:3.5"


    Motor and Pump

    Rewindable motor

    Three-phase:220V/60Hzor380V/60Hz

    Single-phase:110V/60Hz or 220V/60Hz

    Equip with start control box or digital auto-control b

    Pumps are designed by casing stressed

    Curve tolerance according to ISO 9906


    Options on request

    Special mechanical seal

    Other voltages or frequency 50Hz

    Single phase motor with built-in capacitor


    Warranty:2 years

    (according to our general sales conditions)

    • 0.00
      0.00
Product Description

Applications

For water supply from wells or reservoirs

For domestic use, for civil and industrial application:

Forgarden use and irrigation


Operating conditions

Maximum fluid temperature up to +35C

Maximum sand content:0.25%

Minimum well diameter:3.5"


Motor and Pump

Rewindable motor

Three-phase:220V/60Hzor380V/60Hz

Single-phase:110V/60Hz or 220V/60Hz

Equip with start control box or digital auto-control b

Pumps are designed by casing stressed

Curve tolerance according to ISO 9906


Options on request

Special mechanical seal

Other voltages or frequency 50Hz

Single phase motor with built-in capacitor


Warranty:2 years

(according to our general sales conditions)
