  • Control Box
  • Control Box

    Single phase motor starting controller Single phase capacitance operating motor is equipped with a external capacitance and a over-load protector in the starting controller which anc automatically break down power supply(manual recover)when motor over-loading.


    Applications

    For water supply from wells or reservoirs

    For domestic use, for civil and industrial applications

    For garden use and irrigation


    Suitable application range

    Type of motor:Single phase capacitance motor

    Motor power:0.37-1.5kW

    Voltage:220-240V

    Frequence:50Hz


    Product functions

    Protect against short circuit

    Protect for over current


    Installation environment index

    Grade of protection:IP20

    Environmenttemperature :-25℃~+55℃

    Environmenthumidity:(20-90)%


    Operating method

    Manual control

    • 0.00
      0.00
Product Description

Single phase motor starting controller Single phase capacitance operating motor is equipped with a external capacitance and a over-load protector in the starting controller which anc automatically break down power supply(manual recover)when motor over-loading.


Applications

For water supply from wells or reservoirs

For domestic use, for civil and industrial applications

For garden use and irrigation


Suitable application range

Type of motor:Single phase capacitance motor

Motor power:0.37-1.5kW

Voltage:220-240V

Frequence:50Hz


Product functions

Protect against short circuit

Protect for over current


Installation environment index

Grade of protection:IP20

Environmenttemperature :-25℃~+55℃

Environmenthumidity:(20-90)%


Operating method

Manual control
